BTO-22 450mm coil diameter galvanized concertina barbed wirecross razor
Product Description
The razor barbed wire is a new type of fence, with beautiful, economical and practical, prevention effect is good, convenient construction and other excellent characteristics, widely used in many countries of the industrial and mining enterprises, garden apartment, border posts, military field, prisons, detention center, government buildings and other national security facilities. The main material of the product has galvanized board and stainless steel plate.
Razor barbed tape is a kind of modern security fencing materials fabricated with razor-sharp steel blade and high-tensile wire. Barbed Tape can be installed to achieve the result of frightening and stopping to the aggressive perimeter intruders, with piecing and cutting razor blades mounted at the top of the wall, also the special designs making climbing and touching extremely difficult. The wire and strip are galvanized to prevent corrosion.
The Concertina Wire or razor wire is a type of jagged wire produced of galvanized or stainless steel, manufactured in large coils which can be expanded like an accordion, characterized as an element of passive safety.
Product Different Type
Flat warp razor barbed wire is a new type of razor barbed wire. Metal Tec press the single loop razor barbed wire into flat, or press two loops into flat then expand them across. We usually use it together with been line razor barbed wire to build a defencing wall, or use it alone as a fence. It is normally used in community, storehouse, mine, prison, key sites of national defence, etc.
Cross Type Razor Barbed Wire it's also called Double Loops Razor Barbed Wire or Concertina Barbed Wire. It's produced by two pieces of stainless steel razor wire or Zinc-coated Wire which are bound together by clips to make it stronger.
Single Loop Razor Barbed Wire is also called single coil razor barbed wire, it's installed without clips and runs in natural loops on the top of walls or fencings. Single loop razor barbed wire is restless and can be easily installed.
Product Specification
| Razor Blade Parameter: | | |
| Reference Number
| Thickness | Wire Dia | Barb Length
| Barb Width
| Barb Spacing
|
| BTO-12 | 0.5±0.05 | 2.5±0.1 | 12±1 | 15±1 | 26±1 |
| BTO-18 | 0.5±0.05 | 2.5±0.1 | 18±1 | 15±1 | 33±1 |
| BTO-22 | 0.5±0.05 | 2.5±0.1 | 22±1 | 15±1 | 34±1 |
| BTO-28 | 0.5±0.05 | 2.5±0.1 | 28±1 | 15±1 | 34±1 |
| CBT-60 | 0.6±0.05 | 2.5±0.1 | 60±2 | 32±1 | 96±2 |
| CBT-65 | 0.6±0.05 | 2.5±0.1 | 65±2 | 21±1 | 100±2 |
Product Application
Razor barbed wire as a premier security materials with a efficient ability to enhance the whole mesh fence system meanwhile the gallow uncalled strange person ,make the clear countries border line ,protecting and overawe.Concertina barbed wire is the things like this compare with barbed wire its more powerful and more conditions control for you house site security
Packing&shipping
Packing:waterproof paper each into woven bag
As customers request
